Timing Tool Kit For VW Golf MK5 Audi 2.0 FSI / TFSI for Chain and Tensioner Repairs T10252

: In stock

Regular price $179.00 NZD

Camshaft Tools Set for Volkswagen, Audi 2.0 FSI / Turbo FSI / TFSI Turbo / Non Turbo Aftermarket product Tools kit includes: T40011...


Ships between -

QUESTIONS & ANSWERS

Have a Question?

Be the first to ask a question about this.

Ask a Question




Camshaft Tools Set for Volkswagen, Audi 2.0 FSI / Turbo FSI / TFSI Turbo / Non Turbo

Aftermarket product

Tools kit includes:
T40011 Cam Belt Tensioner Locking Pin
T10060 Auxiliary Drive Belt Tensioner Locking Pin
Cam Belt Tensioner Locking Pin
3366 Automatic Chain Tensioner Retainer / Crankshaft Pulley Holding Tool
T10020 Two Pin Tension Wrench
T10252 Camshaft Aligning Tool
T10092 Chain Tensioner Retaining Screw and Nut

Fit:
Audi A3 2.0 FSI SOHC (2003-present) non turbo TFSI Turbo
Engine Code: AXW, BHD, BMB, AWA, AXX, BPY, BWA
Audi A4 2.0 TFSI (2004-present)
Engine Code: BUL
Audi A6 2.0 TFSI (2006-present)
Engine Code: BPJ, BGB
Volkswagen Golf 2.0 FSI SOHC (2003-present)
Engine Code: AXW
Volkswagen Passat 2.0 TFSI (2005-present)
Engine Code: BWA, BWE, BGB, BPJ
Volkswagen Touran 2.0 FSI SOHC (2003-present)
Engine Code: AXW
Volkswagen Eos 2.0 TFSI

Often these engines require not only cam belt but also chain and tension replacement as tensioner can be clogged up and sluggish causing chain to stretch. Symptoms are noise on idle as well as delay and uneven power delivery under acceleration. This kit is necessary to carry out job correctly without costly damage to the engine.

Tool T40080 is also required.

VW / AUDI COMPLETE TIMING TOOL KIT FOR 2.0L TURBO ENGINES FSI AND TFSI

All tools need to make correct timing on 2.0L VW/AUDI Turbo engines.

Packed in blow molded case.

Tools are as pictured.

This is high quality precision made tool, not China copy.

VW / AUDI COMPLETE TIMING TOOL KIT INCLUDES:

T10252     Camshaft Locking Tool     Use to lock both camshafts.

T10060A  Tensioner Locking Pin      Use to lock the tensioner in the loose position.

T10115     Tensioner Locking Pins    Use to lock the timing belt tensioner into place.

T10020     2 Pin Tensioner Wrench   Used to get correct tension on the timing belt.

T40011    Tensioner Locking Pins     Use to lock the timing belt tensioner into place.

3366 CAM CHAIN TENSIONER RETAINER Use to hold the chain and tensioner in position during assembly and disassemble.

NOTE: welding locking pins to the plate may be required. Tool pins sometimes bends, when you trying to undo the bolt if cam adjuster bolt is stubborn. In this case welding it together to make it solid will be required. Alternative buy genuine T10252 tool. Many branded tools give a tiny change but usually result is the same, banana in the next second.

APPLICATIONS (see bellow for full application chart):  VW, Audi FSi, TFSi Turbo 2.0L engines 2004-2009 BELT ENGINEAudi A3 2.0 FSI and FSI SOHC engine codes: AWA, BHD, BMB, VW Golf 2.0 FSI and 2.0 FSI SOHC and Touran 2.0 FSI SOHC engine codes AWA AXW.

Contents:

- Timing belt tensioner Audi: 2.0 FSI, 2.0 TFSI, 1.8 Turbo, 1.8, 2.0, 4.2 petrol, 1.4, 1.9 TDI PD, 2.5 TD, Seat: 2.0 FSI, 1.8 Turbo, 1.6, 2.0 1.4, petrol1.9, 2.0 TDI PD, 2.0 TDI PD FR, 2.0 TDI PD FT4, Skoda: 2.0 FSI, 2.0 vRS, 1.8 Turbo, 2.0 petrol, 1.4, 1.9, 2.0 TDI PD, 2.5 TD, VW: 1.6, 2.0 FSI, 2.0 TFSI, 2.0 GTI FSI, 1.8 GTI, 1.4, 4.2 petrol, 1.2, 1.4, 1.9 TDI PD, 1.9, 2.0 SDI, 1.4 TDI PD BM engines

- Timing belt tensioner Seat: 1.8 Turbo, 1.8 V16. 1.8 Cupra R engines

- Timing belt tensioner Audi: 2.0 TFSI, 2.0 S, 3.0 petrol, 1.9, 2.0 TDI PD, Seat: 2.0 FSI, 2.0 TFSI, 2.0 TFSI FR (Cupra) benzines, 1.4, 1.9, 2.0 TDI PD, 2.0 TDI PD FR, 2.0 TDI PD FT4, VW: 2.0 FSI petrol, 1.4, 1.9, 2.0 TDI PD, 2.0 SDI engines

- Special screw with washing Audi: 1.8 Turbo, 2.0 TFSI, 2.0 S, 1.8, 2.0 Seat: 1.8 Turbo, petrol engines

- Timing chain tensioner Audi: 1.8 Turbo, 1.8, 2.0, 3.7, 4.2, Seat: 1.8 Turbo, 1.4, 1.6 V16, 1.8 Cupra R, 1.4, 1.8, 2.3 petrol, 1.9, 2.0 TDI PD, 1.7, 1.9 SDI, Skoda: 1.8 Turbo, 1.8 Turbo V20 RS petrol: 1.8 Turbo, 2.0 v20, 1.8 petrol engines

- Camshaft locking tool Audi: 2.0 FSI/ TFSI, Seat: 2.0 FR, 2.0 FSI, 2.0 FSI FT4, 2.0 TFSI, 2.0 TFSI FR (Cupra), vw: 2.0  FSI/TFSI

- Camshaft disc tool Audi, Seat,  Skoda, VW

 Suitable for:

  Audi: A2, A3, A4, A4 Cabrio, A4 Quattro, A6, A6 Quattro, Cabrio, A8, S3, Alldoad, RS6, TT

  Seat: Alhambra, Altea, Altea XL, Cordoba, Ibiza, Leon, Toledo

  Skoda: Fabia I-II, Octavia I-II, Octavia Tour, Roomster, Superb

  VW: Golf, EOS, Passat, Jetta, Tiguan, Beetle, Bora, Caddy Maxi, Fox, Lupo, Polo, Sharan, Tiguan, Touran, Transporter

 Engine codes:

Audi: BHC, ATL, AMF, BLX, BMB, BVY, BHD, BLY, AXW, BLR, BVZ, BKC, BLS, ASZ, ATD, AXR, AZV, BKD, BMN, BMM, AXX, BPY, BWA, AWA, AKE, AYM, BCZ, BDH, BAU, BDG, BFC, AFB, AKN, BRF, BVF, BNA, BRE, BLB, BVA, BVG, BUL, AVJ, BFB, AMB, BEX, ALT, BDG, BCZ, BRD, BPJ, AWT, AKN, BCY, BRV, BAM, AUM, APX, ARY, AJQ, APP, AUQ, AVB, AVF, AWX, BKE, BRB, BRC, BPW, BWT, BYK, BBJ, ASN, BHZ, BZC, CDLB, ARH, ARX, AGU, AQA, ARZ, AGN, APG, ANB, AJL, AEB, APU, ATP, AVV, ARG, ADR, AJP, AMK, APY, CDBL, BFV, BVR, AMU, BVP, APT, APJ, BFL, BFM

Seat: BVH, BRT, BLR, BLY, BVZ, BVY, BLS, BJB, BKC, AZV, BKD, BMM, BMN, BGU, BSF, BSE, ASY, BMS, BNV, AMF, BNM, BMT, BPX, BUK, ASZ, ATD, AXR, BLT, AZL, AYP, BJX, BKV, BLZ, BBU, BXE, BFQ, AQX, APY, BAM, AMK, AUQ, APP, AJQ, ARY, AGN, APG, APT, BVK, ANU, AUY, BTB, BUH, BWA, BUY, BUZ, ARL, BWA, BWJ, AWC, AJH, AFK, AQQ, AUB, AKU, BKY, BBY, BXV, BBZ, AFH, AUA, AUB, APE, BXW, AZD, BCB, AUS, AMK, AHW, BCA, AXP, AGZ, BWA1,

Skoda: AMF, BNM, BNV, BMS, BSW, BLS, BVY, BLX, BVX, BUZ, BLR, BLY, BJB, BKC, BKD, AZV, BMN, BWA, AXR, AYM, BDG, AWT, AZM, ARX, AGU, ARZ, AUM, AUQ, AGN, AWT

VW: ATD, AXR, BFS, AYD, AJM, ANU, ARL, ASZ, AUY, APF, AEH, AKL, AVU, BFQ, BLS, BSU, BJB, BGU, BSF, BSE, BST, BDJ, BUZ, BUY, BMM, BPY, BWA, BNM, AXW, BLR, BLY, BUX, BLX, BWA, AXX, BPY, BDK, BRU, BXE, BKC, BXF, AZT, BCA, BRM, AMF, ANY, BKP, BWV, BVE, BMR, BMA, BUZ, BMP, BJX, ASY, BAJ, BMS, BWB, BMT, BLT, BMS, AUR, BTB, BVK, BRT, BKD, AXQ, BHX, AVQ, AXB, AXC, BRR, BRS, BZY, BVX, BVZ, AZV, BMN, AVB, AWX, AVF, BHW, BGW, BNV, BAY, AVC, AUM, AUQ, ARZ, AGU, AQA, BUL, AGN, ALT, AWT, AEB, ANB, APU, ADR, ARG, APT, BBU, AWC, AJH, BVY, AXX
